12G SDI FMC Daughter Card

Our VIDIO 12G SDI FMC Daughter Card equips developers with the latest in broadcast video technology. VIDIO offers 12G SDI and 10G IP interfaces supporting resolutions up to 4Kp60 on select Xilinx Ultrascale, Ultrascale+, Kintex, Virtex, and Zynq, as well as Intel/Altera Arria 10 and Cyclone 10 development boards.

Designed to support Xilinx KCU116, KCU105, KC705, ZCU102/106, Intel Arria 10, Cyclone 10, Stratix 10, and most other development boards supporting the FMC HPC Standard.



Our 12G SDI FMC Card is a single FMC board utilizing the latest technology from Texas Instruments® and boasting full size edge launch BNC’s and an SFP+ for SDI or IP development. Schematics, Gerbers, bill of materials, along with example projects are available to help jump-start your hardware design.

NO SOFTWARE REQUIRED – Unlike other solutions, there is no software or programming required to initialize the VIDIO. It powers up with a default configuration to enable you to use it immediately.

Our field proven VIDIO FMC Development Module has been selected by Intel for use in their Arria 10 and Cyclone 10 User Guide and Reference Designs.

Intel/Altera User Guide and Reference Designs

SDI II Intel FPGA IP Design Example Quick Start Guide for Intel Arria 10 Devices with Nextera FMC Daughter Card
AN 768: Multi-Rate (Up to 12G) SDI II with Nextera FMC Daughter Card Reference Design for Intel Arria 10 Devices
AN 848: Implementing Intel Cyclone 10 GX Triple-Rate SDI II with Nextera FMC Daughter Card Reference Design

Xilinx Reference Designs Available Upon Request

Full Speed Ahead

The VIDIO SDI Interface supports 270M, 1.5G, 3G, 6G, and 12G SDI, while the Ethernet/Video SFP+ interface supports 1G, 2.5G, and 10G. Applications include IP Gateways, Format Converters, and Signal Extenders.

Field Tested and Proven Performance

12G SDI Jitter Performance at 100m

Unmatched 12G SDI Jitter Performance

The VIDIO SDI FMC card was rigorously tested with the latest BERT testers and SDI signal analyzers and offers the best jitter performance on the market. Our 12G SDI FMC board is able to drive 100 meters of 8281 coax and still meet SMPTE jitter specs. VIDIO provides an affordable and effective platform on which to develop new 4K and Video over IP products. To place an order, please contact [email protected].

Part Number

  • VIDIO-12G-X, Xilinx
  • VIDIO-12G-A, Intel

For more info on the 12G SDI devices, see: www.ti.com/sdi
